COVER
24 BOTTOM BOARD 1 60 HEX HEAD BOLTS M8*45 1
25 FANS 1 61 HEAD COUNTERBORE BOLT M6*35 8
26 UPRIGHT COVER L 1 62 CROSS HEAD BOLTS M3*8 2
27 UPRIGHT COVER R 1 63 CROSS HEAD BOLTS M6*16 10
28 LEFT BACK COVER 1 64 CROSS HEAD BOLTS M5*8 7
29 RIGHT BACK COVER 1 65 SCREW ST3.5*35 2
30 SIDE RAIL 2 66 SCREW ST2.9*6.5 19
31 SAFETY MAT 2 67 SCREW ST4.2*12 33
32 RUNNING BELT 1 68 SCREW ST4.0*20 2
33
CAP FOR MOVING
WHEEL
2 69 LOCKWASHER 6 3
34 BELT 1 70 LOCKWASHER 8 18
35 BLUE CUSHION PAD 4 71 LOCKWASHER 10 4
36 BLACK CUSHION PAD 4 72 LOCKWAHSER 8 6
73 FLAT WAHSER 8 6 91 SPEAKER 2
74 FLAT WASHER 10 2 92 SAFETY LOCK COMPONENTS 1
75 COMPUTER 1 93 TRANSFORMER 1
76
COMPUTER BUTTON
PANEL
1 94 STANDARD POWER WIRE 1
77
POWER CONTROL
BOARD
1 95 SQUARE SWITCH 1
78 MAGNETIC SENSOR 1 96 OVERLOAD FUSE 1
79
PULSE WITH INCLINE
BUTTON
1 97 AC SINGLE WIRE 1
80
PULSE WITH SPEED
BUTTON
1 98 AC SINGLE WIRE 1
81
COMPUTER TOP WIRE
1
1 99 AC SINGLE WIRE 1
82 COMPUTER TOP WIRE 1 100 MAGENTIC CORE 1
83
COMPUTER MIDDLE
WIRE
1 101 MAGNETIC RING 1
84
COMPUTER BOTTOM
WIRE
1 102 DC MOTOR 1
85 STICKER 2 103 RUNNING BOARD 1
86
TOP WIRE OF THE
PULSE
1 104 SENSOR SWITCH BOARD 1
87
PULE WITH SWITCH
TOP WIRE
1 105 HANDLEBAR COVER L 1
88
PULSE SPEED TOP
WIRE
1 106 HANDLEBAR COVER L 1
89 INCLINE MOTOR 1 107 HANDLEBAR COVER R 1
90 POWER BOARD 1 108 HANDLEBAR COVER R 1
