Evo 423T - Parts List

www.evofitness.net.au
15
PARTS LIST
NO DESCRIPTION SPECIFICATION QTY NO DESCRIPTION SPECIFICATION QTY
1 MAIN FRAME 1 37 WHEELS 2
2 BASE FRAME 1 38 ADJUSTING ROLLER 2
3 LEFT UPRIGHT 1 39 FOOT PAD 2
4 RIGHT UPRIGHT 1 40 RING PROTECTING WIRE PLUG 2
5 COMPUTER 1 41 POWER WIRE BUCKLE 1
6 MOTOR BRACKET 1 42 SAFETY KEY SPRING BALL 1
7 INCLINE SUPPORT 1 43 ROUND TUBE PLUG 2
8 SCREW M4*12 4 44 FOAM 2
9 ADJUSTING TUBE 4 45 FLAT FOOT PAD 4
10 SPEAKER 2 46 LOCKNUT M6 8
11 HYDRAULIC BAR 1 47 LOCKNUT M8 6
12 FRONT ROLLER 1 48 LOCKNUT M10 2
13 REAR ROLLER 1 49 FLAT HEAD BOLTS M8*16 10
14 ROTATING TUBE 2 50 FLAT HEAD BOLTS M8*25* 15 3
15 SCREW DRIVER
S=13、14、15
1 51
SCREW ST4.2*13 16
16 5# WRENCH 5mm 1 52 FLAT HEAD BOLTS M8*40*20 9
17
SCREW ST2.9*8 2
53 FLAT HEAD BOLTS M10*25 2
18 SAFETY LOCK 1 54 FLAT HEAD BOLTS
M10*45
thread15
1
19 MOTOR UPPER COVER 1 55 FLAT HEAD BOLTS
M10*55 thread
20
1
20
MOTOR LOWER
COVER
1 56 FLAT HEAD BOLTS M10*55 2
21 COMPUTER PANEL 1 57 FLAT HEAD BOLTS M6*45 1
22
COMPUTER UPPER
COVER
1 58 FLAT HEAD BOLTS M6*55 2
23 COMPUTER LOWER 1 59 HEX HEAD BOLTS M8*35 5
