2.Wall Mount
instructions
1. Start by unscrewing the two lower screws
holding the Wall Mount and wall bracket
together.
2. Fasten the Wall Mount bracket on to wall using
suitable wall plugs and fastening screws. The
cord is pre-assembled vertically, but it is
possible to mount it in any direction.
3. Place Wall Mount on top of bracket and fasten
from underneath with the screws which come
2
with the package.
4. Plug in the power adapter to a proper wall
outlet.
5. Slide Minto into place by guiding it onto the back
slot on the Wall Mount’s protruding top edge.
6. When the Evoko Minto is placed on the wall
mount it will automatically charge. When
removed from the Wall Mount, voice feedback is
3
provided on the battery status.
5
NOTE: Glass Wall Mounting Sticker for
mounting on glass walls is available as
an accessory purchased separately
(Art. No. EMX1016
