VARIPUMP 10,000 TO 1½” PRESSURE PIPE
We recommend connecting Varipump 10,000 to 1½” Pressure Pipe.
To do this we recommend screwing a 1½” Single Union, Threaded Female To Plain Female
(EA Code: K82-76-55) onto the inlet and outlet of the Varipump. This also enables easy
access to the pump for maintenance when on a gravity fed set-up.
You can then glue 1½” Pressure Pipe (U15-050) directly into these connectors,
using Solvent Weld Adhesive (EA Code: S79-0-500).
VARIPUMP 20,000 AND 30,000 MODELS TO 2” PRESSURE PIPE
We recommend connecting Varipump 20,000 and 30,000 pumps to 2” Pressure Pipe.
To do this we recommend screwing a 2” Single Union, Threaded Female To Plain Female
(EA Code: K82-76-66) onto the inlet and outlet of the Varipump. This also enables easy
access to the pump for maintenance when on a gravity fed set-up.
You can then glue 2” Pressure Pipe (U15-063) directly into these connectors,
using Solvent Weld Adhesive (EA Code: S79-0-500).
If you want to connect the Varipump 20,000 or 30,000 to 1½” Pressure Pipe, follow steps
above and add a 2” to 1½” Plain Reducing Bush (EA Code: R81-063).
CONNECTING THE VARIPUMP TO PRESSURE PIPE
INLET
OUTLET
Pressure Pipe
Pressure Pipe
Single Union
Threaded Female
To Plain Female
Single Union Threaded
Female To Plain Female
