6 7
www.evolutionpowertools.com www.evolutionpowertools.com
WARNING: the operation of any power tool can
result in foreign objects being thrown towards
your eyes, which could result in severe eye
damage. Before beginning power tool operation,
always wear safety goggles or safety glasses with
side shield or a full face shield where needed.
WARNING: If any parts are missing, do not
operate your machine until the missing parts are
replaced. Failure to follow this rule could result in
serious personal injury.
INTENDED USE OF THIS POWER TOOL
WARNING: This product is a Multipurpose Jigsaw
and has been designed to be used with special
Evolution multipurpose blades. Only use blades
designed for use in this machine and/or those
recommended specically by Evolution Power
Tools Ltd.
When tted with a correct blade
this machine can be used to cut:
• Wood
• Wood Derived Products
(MDF, Chipboard, Plywood,
Blockboard, Hardboard. etc)
• Aluminium
• Mild Steel
PROHIBITED USE OF THIS POWER TOOL
WARNING: This product is a Multipurpose Jigsaw
and must only be used as such. It must not be
modied in any way, or used to power any other
equipment or drive any other accessories other
than those mentioned in this Instruction Manual.
WARNING: This machine is not intended for
use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have
been given supervision or instruction concerning
the safe use of the machine by a person
responsible for their safety.
Children should be supervised to ensure that they
do not have access to, and are not allowed to play
with, this machine.
VIBRATION
WARNING: When using this machine the
operator can be exposed to high levels of vibration
transmitted to the hand and arm. It is possible that
the operator could develop “Vibration white nger
disease” (Raynaud syndrome). This condition can
reduce the sensitivity of the hand to temperature
as well as producing general numbness.
Prolonged or regular users of sanding machines
should monitor the condition of their hands and
ngers closely. If any of the symptoms become
evident, seek immediate medical advice.
• The measurement and assessment of human
exposure to hand-transmitted vibration in the
workplace is given in: BS EN ISO 5349-1:2001
and BS EN ISO 5349-2:2002.
• Many factors can inuence the actual vibration
level during operation e.g. the work surfaces
condition and orientation and the type and
condition of the saw blade being used. Before
each use, such factors should be assessed,
and where possible appropriate working
practices adopted. Managing these factors can
help reduce the effects of vibration:
HANDLING
• Handle the machine with care, allowing the
machine to do the work.
• Avoid using excessive physical effort on any of
the machines controls.
• Consider your security and stability, and the
orientation of the machine during use.
WORK SURFACE
• Consider the work surface material; its condition,
density, strength, rigidity and orientation.
LABELS & SYMBOLS
WARNING: Do not operate machine if warning
and/or instruction labels are missing or damaged.
Contact Evolution Power Tools or your supplier for
replacement labels.
Note: All or some of the following symbols may
appear in the manual or on the product.
Symbol Description
V Volts
A Amperes
Hz Hertz
Min
-1
Speed
~ Alternating Current
n
o
No Load Speed
Wear Safety Goggles
Wear Ear Protection
Do Not Touch
Keep Hands Away
Wear Dust Protection
Restriction of Hazardous
Substances Directive
CE certification
Waste Electrical &
Electronic Equipment
Read Manual
Warning
Laser Warning
JIGSAW SPECIFICATION
Motor
230V ~ 50Hz ........................................... 710W (6A)
110V ~ 60Hz ........................................ 600W (5.2A)
RPM No Load ....................... 0 - 3000min
-1
(rpm)
Recommended Max Duty Cycle ............30mins
Stroke Length ....................................26mm (1”)
Cutting Capacity
Wood ...........................................80mm (3-3/16”)
Metal ................................................. 8mm (5/16”)
Insulation Class ............................................... II
Weight (Gross) .................................4.1kg (9lbs)
Noise & Vibration Data
Sound Pressure L
P
A .............. 87dB(A) K=3dB(A)
Sound Power Level L
W
A ........ 98dB(A) K=3dB(A)
Vibration Level ................... 3:129 m/s
2
K=1.5m/s
2
Note: The vibration measurement was made
under standard conditions in accordance with:
BS EN 610291.2009.
WARNING: The vibration emission during actual
use of the power tool can differ from the declared
total value depending on the ways in which the
tool is used. The need to identify safety measures
and to protect the operator are based on an
estimation of exposure in the actual conditions of
use (taking account of all parts of the operating
cycle, such as the times the tool is switched off,
when it is running idle, in addition to trigger time)
ITEMS SUPPLIED
Instruction Manual .........................................1 pc
Hex Key 4mm ................................................1 pc
Footplate Shoe ..............................................1 pc
Jigsaw Blades............................................1 pack
Parallel Edge Guide.......................................1 pc
Dust Extraction Adaptor .................................1 pc
Chip Guard (Front) ........................................1 pc
Chip Guard (Footplate) ..................................1 pc
Batteries ‘AAA’ ..............................................2 pc
