CUTTING METAL
When cutting any metal a suitable cutting
lubricant/coolant should be used. Cast Iron and
Brass can be cut without a cutting lubricant.
Always use a blade that is capable of cutting
metal, and secure the workpiece securely, if
practicable, in a vice or similar clamping device.
WARNING: When cutting metal the Cutting Action
Selection Lever must be set to the ‘0’ position.
CUTTING CIRCLES OR CURVES
When cutting curves, particularly tight curves,
start with a reasonably slow speed, and gradually
increase the speed until the optimum performance
is achieved. Do not force the blade, as in curved
cutting this can lead to the blade deection, and
possible blade breakage.
To cut a circle from a workpiece:
• Mark out the circle in the required postion.
• Drill a Ø12 mm hole near the centre of the circle.
• Insert the jigsaw blade into the ø12 mm hole.
Ensure that there is clearance between the
blade and the workpiece.
• Begin cutting towards the outside of the circle,
slowly in a spiral fashion, until the blade is
following the required cutting line.
• Advance the jigsaw slowly to avoid cutting a
slanted surface or experiencing blade deection.
ANGLED CUTTING
Angled cutting, whatever the material, is always
more difcult than general straight cutting. With
angled cutting it is very important to allow the saw
blade to do the work. Do not ‘force’ the blade. A
trial run on unwanted material to determine the
best combination of blade feed and speed is
recommended.
Return to the factory setting when angled cutting
is completed. Recheck the security of the blade.
BLADES
Choose blades carefully. Use only a blade that is
suitable for this machine and for the material to
be cut.
The ability of any jigsaw to follow curves, provide
smooth nishes or faster cutting is directly related
to the type of blade employed.
MAINTENANCE
Your Evolution Jigsaw requires no major additional
lubrication or maintenance. Occasionally apply
a drop of light machine oil to the blade guide
spindle. There are no user serviceable parts in
your Evolution Jigsaw.
Keep the tool clean, but do not use chemical
cleaners which may damage the plastic parts.
Clean with a dry cloth. Ensure that the motor
ventilation slots are kept clean.
ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed
of with household waste. Please recycle where
facilities exist. Check with your Local Authority or
retailer for recycling advice.
EC DECLARATION OF CONFORMITY
In accordance with EN ISO 17050-1:2004
The manufacturer of the product covered by this Declaration is:
Evolution Power Tools, Venture One, Longacre Close, Holbrook Industrial Estate, Sheffield, S20 3FR
The manufacturer hereby declares that the machine as detailed in this declaration fulfils all the
relevant provisions of the Machinery Directive and other appropriate directives as detailed below. The
manufacture further declares that the machine as detailed in this declaration, where applicable, fulfils
the relevant provisions of the Essential Health and Safety requirements.
The Directives covered by this Declaration are as detailed below:
2006/42/EC Machinery Directive
2004/108/EC Electromagnetic Compatibility Directive
93/68/EC The CE Marking Directive
2002/95/EC The Restriction of the Use of certain Hazardous Substances in Electrical Equipment (RoHS) Directive
2002/96/EC As amended by 2003/108/EC. The Waste Electrical and Electronic Equipment (WEEE) Directive
And is in conformity with the applicable requirements of the following documents
EN 60745-1:2009+A11:2010
EN 60825-1:2007
EN 60745-2-3:2011
EN55014-1:2006/+A1:2009
EN 55014-2:1997/+2001/+A2:2008
EN 61000-3-2:2006/+A1:2009/+A2:2009
EN 61000-3-3:2008
Product Details
Description: RAGE7-S 710W Corded Jigsaw With Variable Speed Control
Evolution Model No: RAGE7-S2 (075-0001) / RAGE7-S1 (075-0002) / RAGE7-S2EU (075-0003)
Factory Model No: HDA1110
Brand Name: EVOLUTION
Voltage: 110V / 230V
Input: 50HZ / 60HZ
The technical documentation required to demonstrate that the product meets the requirements of directive has been
compiled and is available for inspection by the relevant enforcement authorities, and verifies that our technical file
contains the documents listed above and that they are the correct standards for the product as detailed above.
Name and address of technical documentation holder.
Signed: Print: Steven Bulloss: Operations Director Year that CE was first applied
Signed: Print: Lettie Lui: Product Manager
Date: 01/12/12
