Evolveo StrongVision PRO - Technical Specifications

68
3. Technical Specifications
3.1 General
Display
Colour TFT 2.4”
Movement sensor
PIR (Passive Infrared) – adjustable
sensitivity (3 levels)
Detection angle of the
movement sensor
120°
Night illumination
IR LED 940 nm, 58 LED under the
front antireflective cover
IR LED beam distance
20 m *
Dimensions
H x W x D 187** x 118 x 87 mm
Operating
temperature
-10°C to +50°C
Storage temperature
-15°C to +60°C
Ingress protection
IP65
Security
4-digit optional password
Operating
temperature
-10°C to +55°C
* Night images may be dark if there are no other objects in the
area in front of the camera from which the IR illumination may be
reflected. Ideally, there should be objects in the area in front of
the camera from which the IR illumination can be reflected, such
as stones, shrubs, trunks and the like. The optimal beam distance
is 8–12 m from the camera
** Including a mounted antenna bent to 90°, height including a
straightened antenna 347 mm
