LCD Screen People Counter - Installation and Operation Guide
© 2016 EvolvePlus Pty Ltd 3 www.evolveplus.com.au
Overview – PRx20D1 – PTx20-1(Bi-directional)
The PRx20D1 - PTx20-1 (LCD screen display model) is a bi-directional people counter. The principle is based
on the interruption of a horizontal infrared beam.
The transmitter PTx20-1 transmits the infrared beam to the receiver "PRx20D1". When this infrared beam is
interrupted, e.g. by a person, the receiver detects this and will increase the internal counter.
The PRx20D2 is direction sensitive, which means that counts in both directions are captured and stored
separately.
The counter can run for approximately up to 1 year on a set of batteries, without compromising the counting
distance.
Overview – PRx10D1 – PTx10-1(Uni-directional)
The PRx10D1 – PTx10-1 (LCD screen display model) is a uni-directional people counter. The principle is
based on the interruption of a horizontal infrared beam.
The transmitter PTx10-1 transmits the infrared beam to the receiver "PRx10D1". When this infrared beam is
interrupted, e.g. by a person, the receiver detects this and will increase the internal counter.
The PRx10D1 is not direction sensitive, which means that counts from both directions are captured and stored
together.
The counter can run for approximately up to 3 years on a set of batteries, without compromising the counting
distance.
Specifications
Mechanical
Dimensions 116.4 x 68.6 x 22.3 mm
Material ABS black
Electrical
Power supply 2 x 1.5V AA
Battery life
• PRx20D1 & PTx20-1 : approx. 1 year
• PRx10D1 & PTx10-1 : up to 3 years
Operational
Measurement width
• PRx20D1 & PTx20-1 : 6 metres
• PRx10D1 & PTx10-1 : 8 metres
Maximum count value
• PRx20D1 & PTx20-1 : 999999 in both directions
• PRx10D1 & PTx10-1 : 999999
Delivered content
• Receiver (PRx20D1 or PRx10D1)
• Transmitter (PTx20-1 or PTx10-1)
• Magnet key hanger
• Screwdriver
• 2x Screw to lock covers
• 4x AA Alkaline Batteries
• Installation Guide
Additional content
• Right angled metal mounting brackets
