2.4.1. Operating Environment
The LX module requires indoor installation out of direct sunlight. The maximum ambient
temperature should not exceed 113 °F (45° C). The module can tolerate humidity of up
to 90%, as long as condensation does not occur.
2.4.2. Space Requirements
The physical dimensions of the LX modules are given in appendix A.1. In addition to the
size of the module itself, the arrangement of the piping and the electrical connections will
determine the amount of space the module needs to operate. This arrangement varies
from site to site. Space should be allowed for module servicing/replacement.
2.4.3. Module Orientation
The LX modules must be installed vertically and fastened to the system frame by the L-
shaped feet on the bottom of the module.
2.4.4. DC Electrical Requirements
The LX module DC power requirements are listed in Table 2-2. In all cases the cathode
must be at ground potential. Connections are shown in section 3.4 and Appendix B3.
Table 2-2. DC Power Requirements for the LX Modules
LX Model ► EU, X, Z HI
LX Size ▼ Max DC Volts DC Amps Max DC Volts DC Amps
IP-LXM04 27 1-6 50 1-10
IP-LXM10 67
1-6
125
1-10
IP-LXM18 120
1-6
225
1-10
IP-LXM24 160
1-6
300
1-10
IP-LXM30 200
1-6
375
1-10
IP-LXM45 300
1-6
565
1-10
NOTE: The DC3 power supply (maximum 600 VDC) can be used with all LX models. The
DCR power supply can also be used but requires correct sizing of isolation transformer.
2.4.5. Feed Water Requirements
Feed water for the LX module must always meet the specifications outlined in Table 2-3.
In most cases, pre-treating LX module feed water with reverse osmosis (RO) will bring it
