Evoqua Neptune Benson Defender FP Series User Manual

Page 7 | 26 Rev: 01/18/2021
Installing the Control Enclosure and Filter/Regulator
Figure 4: Control Enclosure and Filter/Regulator
0.5 inch hard pipe
from compressor
Do not use PVC
(not included)
0.5 inch shut off
valve (not included)
0.5 inch
instant fitting
0.5 inch hose
to solenoid
Manifold block
Tubing to valves (included)
See pneumatic tubing installation
Filter/Regulator
