AirKey system manual version 2.7 |
06/03/2024 | Subject to technical changes and misprints
8.7.1 Battery replacements in AirKey cylinders
Replace batteries when the door is open and secured so it does not
accidentally slam shut.
Please note the AirKey cylinder time remains active for a maximum of one
minute after having removed the batteries.
We highly recommend replacing the seals of the AirKey cylinder upon
replacing batteries to continue to guarantee the unit is correctly protected
from humidity. In this process, the seal between thumb turn sleeve and
outside thumb turn as well as the seals in the thumb turn disc of the
outside thumb turn are affected. All these seals are available as spare parts.
For this purpose, please contact your specialist EVVA retailer.
We highly recommend lubricating AirKey cylinders, at minimum upon
replacing batteries. For this purpose, apply a drop of the lubricant
recommended by EVVA between the thumb turn sleeve and the cylinder
housing from the outside after having removed the outside thumb turn. We
additionally recommend you lubricating the rear of the cylinder between
cam and cylinder housing if you temporarily remove the AirKey cylinder. For
this purpose, please contact your specialist EVVA retailer.
> Lock the locking component using a valid medium.
> Position the assembly tool on the cylinder before it disengages.
> Remove the thumb turn of the cylinder with the positioned assembly tool by turning
the screw anti-clockwise.
> Remove the assembly tool from the thumb turn.
> Open the thumb turn by undoing the three screws on the rear of the thumb turn.
> Remove the thumb turn disc of the thumb turn.
> Carefully undo the battery holder by moving it upwards.
> Subsequently replace the batteries. Ensure you re-insert the batteries correctly. In
this process, do not use old and new batteries together.
> Carefully secure the battery holder.
> Position the thumb turn disc on the thumb turn and secure it with the three screws.
> Position the assembly tool on the thumb turn.
> Ensure the seal has been positioned correctly on the cylinder axis and once again
attach the thumb turn to the cylinder by turning it clockwise until you feel a
resistance.
> Remove the assembly tool.
> Subsequently turn the thumb turn anti-clockwise until you notice it engages.
> Ensure the thumb turn and electronics module have engaged correctly.
