Electronic cylinder
The e-primo cylinder in detail
1 Thumb turn cover/inside thumb turn
2 Battery in battery compartment
3 Battery clip
4 Inside locating screw
5 Groove
6 Outside thumb turn
7 Gasket
8 Outside thumb turn
9 Light ring
10 Reader
11 Fixing screw
12 Outside locating screw
13 Cam
14 INIT button
Technical data
Dimensions
Outside thumb turn (conical):
– e-primo iButton: Ø max. 35 mm, length 31 mm
– e-primo air: Ø max. 35 mm, length 32.5 mm
Inside thumb turn (conical): Ø max. 40 mm, length 56 mm
Power supply
1 × standard lithium battery, Panasonic CR 123A
Humidity
Up to 90 %, non-condensing
Temperature range
Inside thumb turn: –20° C to +60° C
Outside thumb turn: –20° C to +60° C
Protection class
IP 65
Certications
– EN 1634-1 re protection
– CE
– Diverse certications with various lock manufacturers
per EN 179 and EN 1125 (optional)
