Chapter 5
Check Card Detection on the Embedded Web
Page
5. Check Card Detection on the Embedded Web Page
The eWON Flexy Extension Card requires no software configuration. It is automatically
detected by the Base Unit when it boots.
5.1. Connecting to the Embedded Web Server
Configure the network parameters of your configuration PC to encompass the IP range of
the eWON LAN.
Connect the PC to one of the LAN port of the eWON Flexy.
Open your Internet browser and access the eWON Flexy internal Web page by entering the
LAN IP address in the URL field (the default address is http://10.0.0.53).
The default
• login is adm
• password is adm
- Warning -
For security reasons, changing the default password adm is absolutely required.
To change the adm password, from the menu bar, click on Configuration, Users Setup and double
click on the adm entry to edit its parameters. Enter the new password twice and click Save.
5.2. Detected Cards Displayed in the System Page
The detected card appears in the eWON System hardware configuration page like shown
below.
The path to the System hardware configuration page showing the cards detected by the
Base Unit is: Diagnostic (1) > Status (2) > System Info (3) > System (4). The screen capture
below gives an example of an FLX 3101 extension card that has been detected in slot 1 (5).
Page 14 / 15 eWON Flexy Single Ethernet Ext. Card FLX3101 | IG 017
