Installer Programmable Features (cont’d)
Feature #5 - Light Relay Function
Dome Light Output (press LOCK to program)
Start (press UNLOCK to program)
Ignition Output (press TRUNK to program)
Accessory Output (press START to program)
Status (press LOCK & UNLOCK to program)
Light Flash (press TRUNK & START to program)
The system has two built-in relays, which can be programmed to perform several different
functions. The primary function of this relay, is to use for vehicle with multi-plex parking
light systems. This relay can be programmed for any other functions listed above.
Feature #7 - Starter Cranking Time
0.75 Second (press LOCK to program)
1.00 Second (press UNLOCK to program)
1.5 Seconds (press TRUNK to program)
2.25 Seconds (press START to program)
3 Seconds (press LOCK & UNLOCK to program)
Average (press TRUNK & START to program)
This feature determines the crank time of the 1st start attempt when in “Tachless” mode.
If the engine doesn’t start on the rst attempt, it will retry up to 3 more times extending
the crank time by an additional 0.2 second with each attempt. The “Average” setting will
sample the last 8 cranks (by ignition key) and average the crank time automatically for
increased accuracy.
Feature #8 - Door Lock/Unlock Outputs
0.8 Second Outputs (press LOCK to program)
3 Second Outputs (press UNLOCK to program)
Double Pulse Unlock Output (press TRUNK to program)
Total Closure Lock Output (press START to program)
This changes the system’s door lock outputs to suite different vehicle requirements. The
total closure setting provides a 28 second lock pulse (press LOCK or UNLOCK is during
the pulse to stop it) and a 0.8 second unlock pulse.
Feature #9 Remote Start Lock Control
Off (press LOCK to program)
Lock After Start (press UNLOCK to program)
Unlock Before Start (press TRUNK to program)
Unlock Before Start & Lock After Start (press START to program)
Lock After Engine Off (press LOCK & UNLOCK to program)
This feature allows for OEM alarm/lock control in relation to remote start operations thus
eliminating extra wiring for OEM alarm control.
Feature #6 Blue Satellite Port, Blue Wire Function
Ignition (press LOCK to program)
Status / GWR (press UNLOCK to program)
Defrost 0.8 sec Pulse (press TRUNK to program)
Defrost 10 min Pulse (press START to program)
Pulse After Engine Off (press LOCK & UNLOCK to program)
Horn (press TRUNK & START to program)
This determines the function of the Blue wire on the Blue satellite relay port.
The Status setting turns on briey before the Ignition output and stays on during remote
start mode. The other pulse settings give a 0.8 second pulse under the selected condi-
tion. Defrost Pulse will send a pulse after start only when the cabin temperature is below
freezing (32 degrees F / 0 degrees C).
24
