119649 3-1 REV A
ASSEMBLY INSTRUCTION
These instructions apply to the assembly of the Excel Two
Bag Catcher to an Excel 42” or 52" mower.
It is intended that these units be installed by trained Excel
service personnel. If additional assistance is required, contact
the Excel Customer Service Department.
Directions given in these instructions, for example left and
right, refer to direction while seated on the mower.
Before proceeding, read thru the following instructions to
familiarize yourself, while at the same time identify and
inventory kit parts supplied.
Unpack and inspect all parts. Notify carrier of any shipping
damages immediately.
Required Tools
The following is a list of the tools required to assemble the
catcher to the mower.
• Tape measure
• One 3/8” combination wrench or socket
• One 1/2” combination wrench or socket
• Two 9/16” combination wrench or socket
• Torque wrench (with 48 ft.-lb. range) with a 5/8” hex
socket
Parts List
NOTE: Refer to the Parts Manual section (starting on page 7-
1) of this manual for more detailed parts information.
Assembly
NOTE: Refer to illustrated parts listings when assembling the
unit.
PART NO. DESCRIPTION QTY.
N/A 2 BAG LID 1
N/A CATCHER CHUTE 1
N/A 1.6 BUSHEL BAG 2
603848 BLADE, 17.86"-CAT-F-CW (52” DECK) 1
793935 BLADE, 20.50"-CAT-F-CW (42” DECK) 1
117394 CATCHER FRAME 1
604387 UPPER CHUTE 1
604375 WEIGHT 2
604301 TIE ROD 2
117303 LS SUPPORT GUSSET 1
117304 RS SUPPORT GUSSET 1
117307 WEIGHT SUPPORT 1
117309 WEIGHT HOLD DOWN 1
117690 RS LEG MOUNT 1
117691 LS LEG MOUNT 1
792002 KNOB 5/16-18 X 3/4" 1
029629 CAP SCREW (CS) .375-16 X .75 HX FLK 8
016899 NUT .375-16 HX FLK ZNYC 8
086660 NUT .375-16 HX ZY NL 2
037887 CARRIAGE BOLT .312-18 X 1.00 2
768523 FLAT WASHER .343 X .687 X .051/.080H 2
058776 NUT .312-18 HX ZY NL 2
023036 HAIR PIN .148 X 2.69 ZN 2
604887 CE .375 x 3.00 WITH BALE 2
604806 PLASTIC CAP - TANK 1
000331 WIRE TIE 2
WARNING
Allow engine and muffler to cool before assembling the
catcher to the mower.
