8- ENG
A20116
Risk of personal
injury. Avoid
placing hands between handle and
frame when assembling to prevent
pinching.
4. To Assemble Accessories Panel
a. Align the screw boss on the
accessories panel assembly
with the hole in the handle
and slide accessories panel
assembly onto handle.
b. Secure accessories panel
assembly to handle with
screws. Do not overtighten.
ASSEMBLY INSTRUCTIONS
1. Locate and remove all loose
parts from the carton.
2. Cut four corners of the carton from
top to bottom and lay the panels
fl at.
3. Place handle onto frame, depress
the snap buttons, and slide the
handle assembly onto the frame
until snap buttons snap into place.
CARTON CONTENTS
Bagged Parts
Engine Frame
and Wheel
Assembly
High Pressure
Hose
Chemical
Hose
Engine
Manual
Handle
Accessories
Panel
Screws
Operation
Manual
Spray Gun
Gatling Spray Wand
Cleaning Tool
