Wiring
Power must be turned off at the circuit breaker before
performing any wiring. Be sure to follow Local and NEC electrical
codes. To provide safe operation, Excelpool System must be
properly grounded and bonded.
Input Power for stand-alone operation:
Wire the Excelpool System to the LOAD SIDE of the filter pump
timer. It is very important that the Excelpool System is powered
only when the pump is running.
Refer to the wiring label on Excelpool System as well as the
diagram below to determine correct wiring connections.
The Excelpool System is shipped from the factory with the
configuration jumpers in a separate bag. Until the jumpers
are installed for the desired voltage, the unit should NOT be
turned on.
21 | P a g e
