Mounting of the exhaust pipe
• Use only the hose provided and clip
exhaust hose to the back of the air
conditioner
• Avoid kinks and bends in the exhaust
hose as this will cause expelled
moist air to build up causing the unit
to overheat and shut down. Fig 9 &
10 show correct position
• The hose may be extended from
300mm to 1500mm but for maximum
efficiency use the shortest length
possible.
WARNING!
The length of the exhaust pipe is specially
designed according to the specification of this
product. Do not replace or prolong it with your
own private hose as this could cause the unit
to mal-function.
FIG.5
FIG.6
FIG.7
FIG.8
