4
PARTS
Front
Back
FIG.5
FIG.6
1. Control Panel
2. Remote control receiver
3. Air vent
4. Carrying handle
5. Water gate (for energy saving)
6. See-through window for water
level inside the unit
7. Air filter (air inlet)
8. Cord compartment
9. Exhaust air outlet
10. Drainage knob / drainage point
11. Air filter (air inlet)
12. Air filter (air inlet)
Accessories
13. Exhaust hose.
14. Flat Type Adaptor – Inserting
over house and into window
spacer
15. Inward adaptor (connecting unit
& exhaust hose)
16. PVC strip - for filling the open
window space
17. PVC strip - for filling the open
window space
18. PVC strip (with hole) - for filling
the open window space and with
hole for connection to flat type
adapter
19. Drain tube for continuous
drainage
20. Active carbon filter
21. Remote control
FIG.7
