Installation of the carbon filter

FIG.15

1. Remove the filter frame from the

unit.

2. Separate the filter fixer from the

filter frame.

3. Remove the active carbon filter from

its plastic bag.

4. Insert the active carbon filter into

the filter frame.

5. Fix the filter by reassembling the

fixer onto the filter frame.

6. Re-fit the filter frame inside the unit.

FIG.16
