EXCURSION HXA20 - Rear Panel Layout

4
REAR PANEL LAYOUT
Fig 2. 2-ch amplifier panel layout
Fig 1. 4-ch amplifier panel layout
Fig 3. Mono amplifier panel layout
16 17 1815
16 17 1815
16 17 1815
(HXA65 / HXA 85 - 8GA SPK and 4GA POWER allen screw Terminal)
(HXA30 / HXA 40 - 8GA SPK and 4GA POWER allen screw Terminal)
(HXA2K / HXA3K - 8GA SPK and 4GA POWER allen screw Terminal)
(HXA4K / HXA5K - 8GA SPK and 0GA POWER allen screw Terminal)
