REAR PANEL LAYOUT

Fig 2. 2-ch ampliﬁer panel layout

Fig 1. 4-ch ampliﬁer panel layout

Fig 3. Mono ampliﬁer panel layout

16 17 1815

(HXA65 / HXA 85 - 8GA SPK and 4GA POWER allen screw Terminal)

(HXA30 / HXA 40 - 8GA SPK and 4GA POWER allen screw Terminal)

(HXA2K / HXA3K - 8GA SPK and 4GA POWER allen screw Terminal)

(HXA4K / HXA5K - 8GA SPK and 0GA POWER allen screw Terminal)
