50-PIECE AIR TOOL KIT
G
J
5
B1
J
4
6
4. Choose the correct impact socket (J) as
needed and mount it onto the anvil (B1).
(See Figure 4)
5. If necessary, use the 1/2" extension bar (G)
and then mount impact socket onto the bar.
(See Figure 5)
6. Connect air supply hose to the male plug.
(See Figure 6)
7. Set the working pressure at 90psi/6.3bar for
best tool performance.
NOTE: Working pressure refers to the
air line pressure set to tool when tool
is under working conditions.
WARNING! Only use impact sockets
that have a RPM and Torque rating
equal to or greater than the tool itself.
12
