EXELAIR EX5005KIT - 1;4 Air die Grinder

50-PIECE AIR TOOL KIT
1/4" AIR DIE GRINDER
EXPLODED DIAGRAM AND PARTS LIST
Part No.
Description
Qty.
Part No.
Description
Qty.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
Housing*
Trigger*
Lever*
Spring*
Pin*
Trigger pin*
Soft grip*
O-ring - EX1425DG1-08
O-ring - EX1425DG1-09
Valve stem*
Valve spring*
O-ring*
Valve plug*
Valve bushing*
O-ring*
Exhaust deflector*
O-ring*
Air regulator*
Set plate*
O-ring*
Set plate*
Gasket*
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
Air inlet*
Housing cover*
Gasket*
Bearing*
Rear plate*
Pin*
Rotor*
Rotor blade - EX1425DG1-30
Cylinder*
Rotor collar*
Front plate*
Pin*
Bearing*
Valve bushing*
Clamp nut*
Protector*
Collet holder*
Collet*
Collet jacket*
Small wrench*
Large wrench*
1
1
1
1
1
2
1
4
1
1
1
1
1
1
1
1
1
1
1
1
1
21
22
23
7
41
33
35
25
4
3
5
17
24
40
39
38
37
36
28
2
6
18
19
20
17
16
15
14
1
28
30
29
27
26
31
32
42
43
10
11
12
13
8
9
34
27
*Replacement part not available
