EXELAIR EX5005KIT - Assembly; 1;2 Air Impact Wrench Assembly

50-PIECE AIR TOOL KIT
ASSEMBLY
E1
2
3
1. Remove the air inlet protective cap from the
air inlet (E1). (See Figure 1)
2. Mount a male plug by hand into the air
inlet (E1). (See Figure 2)
3. Place 2 - 3 drops of air tool oil into the male
plug before each use. (See Figure 3)
E1
1
NOTE: Use thread sealant tape
on the male plug and tighten it with
a wrench for airtight connection.
Do not overtighten.
1/2" AIR IMPACT WRENCH
11
