XP600/1100/2000 INSTALLATION AND OPERATION MANUAL
APPENDIX C
INSTALLATION
CAUTION:
ATTENTION:
.
.
.
Terminate all connections to the inverter BEFORE
connecting DC leads to the battery.
Mettre fin à toutes les connexions à l'onduleur
avant de brancher mène à la batterie.
XP-600 and XP-1100 Rear View with access cover removed
(AC/DC Connections):
BAT -
BAT +
GROUND
NEUTRAL
LINE
REMOTE
Bonding
strip
Negative
Ground
Battery
Inverter
+
-
Appropriately rated fuse.
+
-
Positive
Ground
Battery
Inverter
Appropriately rated fuse.
+
-
+
-
Page 16
To Next Page
