Getting Started with Your Unit
OTAU-9150 25
Connecting Your Unit to a Power Source
6. Unscrew the four screws (shown in gray) located at the top of the
terminal block.
7. Pair the power leads with the appropriate power terminal for each of
the feed, respecting the polarity as indicated on the terminal block.
First feed
Second feed
