Exide 12/3.8 - Technical Specifications

9
GB
TECHNICAL SPECIFICATIONS
Model: EXIDE 12/3.8
EXIDE 12/3.8 is a primary-switched computer-controlled charger.
Input voltage 220-240 VAC +/-10%
Input current Max 1 A
Back current ≤1 mA
Charge voltage 13,7 – 15,5 VDC
Charging current Max 3.8 A
Ripple voltage Max 70 mV
Ambient temperature - 40 – + 50ºC
Cooling Convection
Type of charge 5 step, I
1
, I
2
, I
3
, U, U
h
U
h
: 13,7 V (Maintenance charge)
Lead-acid battery types AGM/GEL, standard batteries
Battery capacity 1 – 75 Ah
Cabling Battery cable 1400 mm
Power cable 2x0,75 mm
2
1400 mm
Dimensions (LxWxH) 204x43x43 mm
International Protection rating IP 44
Weight 0,3 kg
CE MANUFACTURER’S DECLARATION
Manufacturer: EXIDE Technologies, Kungälv, Sweden
and Primepower AB, Växjö, Sweden
Product: Battery charger EXIDE 12/3.8
The manufacturer guarantees that the
unit complies with the relevant standards.
