Operation
ToadjusttheFRSbafes:
1.Stopengine,waitforallmovingpartstostopand
removekey.Engageparkingbrake.
2.Removehairpinsandclevispinsfrombothsides
ofthePTOguard(seeFigure5).Foldguard
forward.
3.LoosennylocnutsontherearstudsoftheFRS
bafes.
Figure10
1.PTOguardremovedfor
clarity
2.Loosennylocnuts
4.RaisedeckasstatedinRaisingtheMowerDeck
totheServicePositionsection.
5.Removeboltandwasheratthefrontofeach
oftheFRSbafes.Rotatebafesintodesired
positionandreinstallboltandwasher.
Figure11
1.Bafesshowninclosedposition
2.Bafesshowninopenposition
3.Bolt
4.Washer
5.Bafes
6.LowerdeckperLoweringtheMowerDeckto
theOperatingPositionsection.
7.SnugnylocnutsontherearstudsoftheFRS
bafes.Thesenutsmaybeleftslightlylooseif
frequentbafeadjustmentisanticipated.
8.ReinstallPTOguardusingclevispinsandhair
pinsremovedinstep2.
