Exmark 4500-370 - Adjusting Fill Reduction System (FRS) Baffles

Operation
Figure8
1.Decklifthandle
2.Rotatethedecklockingpintowardtherearandpull
outwardtounlock.
3.Pushthedecklockingpininandrotatetowardthefront
tolock.
3.Usingdecklifthandle,liftdeckupandlatchin
“up”position(latchislocatedatfrontcenterof
seat)(seeFigure9).
Figure9
1.Securethedeckin
theraisedpositionby
securingthedecklatch
ontothehook.
2.Hook
WARNING
Operatingthemowerdeckintheraised
servicepositioncanbedangerous.Engaging
thePTOwithadeckintheraisedposition
canresultinaseriousinjuryorproperty
damage.
Alwayslowerandlockmowerdeckinthe
operationpositionbeforeengagingthePTO.
LoweringtheMowerDecktothe
OperatingPosition
1.Whilermlyholdingontodecklifthandle,
unhookdecklatchfromtractorsectionandslowly
lowerdecktoground(seeFigure9).
2.Pushdecklockingpinsinwardandrotateforward
tosecurelylockdeckinloweredposition(see
Figure8).
WARNING
Operatingmowerwithoutlockingpins
securelylatchedcanresultinthemowerdeck
foldingupunexpectedly.Themowerdeck
foldingupunexpectedlycancauseserious
injury.
Alwaysoperatemowerwithlockingpins
securelylatched.
AdjustingFillReduction
System(FRS)Bafes
TheNavigator’sexclusiveFillReductionSystemhas
beendesignedtoallowyoutoreducetheamountof
clippingscollectedbyvaryingdegrees.
Advantagesincludelessfrequentemptyingofthe
hopperandreturnofnutrientstothesoil.
PossibleCongurations:
1.Bafesopen,standardblades–Maximum
collection
2.Bafesclosed,standardblades–Partialmulching
3.Bafesclosed,mulchblades–Intermediate
mulching
4.Mulchpluginstalled,mulchblades–Complete
mulching(requiresmulchkit)
12
