Exor eSMART Series User Manual

11
MANUGENESMARTxx - Version 2.01
© 2018 EXOR International S.p.A. - Subject to change without notice
4 Technical Data
Model eSMART04 eSMART04M
Display / Backlight TFT Color / LED TFT Color / LED
Colors 64K 64K
Resolution 480X272 480X272
Diagonal (inches) 4.3” widescreen 4.3” widescreen
Dimming yes yes
User memory 60 MB Flash 60 MB Flash
RAM 256 MB DDR 512 MB DDR
Serial Port
RS-232,RS-485, RS-422
software congurable
RS-232,RS-485, RS-422
DB9 female software congurable
Ethernet port
10/100 Mbit 10/100 Mbit
USB port
Host interface V2.0 max. 500mA Host interface V2.0 max. 500mA
Real Time Clock
yes yes
Voltage
24Vdc 24Vdc
Current rating (at 24VDC)
0.25A 0.25A
Weight
0.4 Kg 0.4 Kg
