Exor eX700 Series - Page 14

14
MANUGENEX7xx - Version 2.09
© 2018-2020 EXOR International S.p.A. - Subject to change without notice
4 Technical Data
Cut out
MODEL A B C
D E F
eX707 187mm/7.36” 147mm/5.79” 176mm/6.90” 136mm/5.35” 47mm/1.85” 8mm/0.31”
eX710 282mm/11.10” 197mm/7.80” 271mm/10.67” 186mm/7.32” 56mm/2.20” 8mm/0.31”
eX712 344,5mm/13.56” 163mm/6.41” 332,5mm/13,09” 163mm/6,41” 49mm/1,92” 8mm/0,31”
eX715 422mm/16.60” 267mm/10.50” 411mm/16.18” 256mm/10.00” 56mm/2.20” 8mm/0.31”
eX721 552mm/21.73” 347mm/13.66” 541mm/21.30” 336mm/13.22” 56mm/2.20” 8mm/0.31”
