MANUGENEX7xx - Version 2.09
© 2018-2020 EXOR International S.p.A. - Subject to change without notice
4 T
echnical Data
4.4 Installation Procedure
Place the xing brackets contained in the xing kit as shown in gure
4.3 Safety instruction
For all installation notes, please ref
er to the Installation Guide provided with the pr
oduct.
!
CAUTION
Tightening torque: 130Ncm or scr
ew each xing screw until the bezel corner gets in contact with the panel.
15
17
