EXPERT GRILL CBT2020W-U - Parts and Hardware Identification

5
1
Lid Handle
2
Lid Air Vent
3
Brand Plate
4
Lid
5
Warming Rack
6
Cooking Grid
7
Top Hinge (2)
8
Bottom Hinge (2)
9
Charcoal Grid
10
Bottom Bowl
11
Side Handle (2)
12
Cooking Grid Handle (2)
13
Lock
14
Heat Resistant Plate
15
Left Leg Assembly
16
Right Leg Assembly
* Pre-assembled
Parts List
A
Screw
M4x10 Nickel Plated Phillips Truss Head
4 pcs
B
Screw
M5x12 Nickel Plated Phillips Truss Head
9 pcs
C
Screw
M6x12 Nickel Plated Phillips Truss Head
4 pcs
D
Wing Nut
M4 Steel
4 pcs
E
Wing Nut
M5 Steel
9 pcs
F
Wing Nut
M6 Steel
6 pcs
G
Washer
ø5 Nickel Plated
9 pcs
H
Washer
ø6 Nickel Plated
10 pcs
I
Washer
ø6 Heat Resistant Washer
14 pcs
J
Lock Washer
ø5 Nickel Plated
8 pcs
K
Lock Washer
ø6 Nickel Plated
6 pcs
L
Pin
ø5x32 Nickel Plated
2 pcs
M
Cotter Pin
ø1.4x30 Nickel Plated
2 pcs
Hardware
Tools Required for Assembly (Not Included)
#2 Phillips Head Screwdriver 1 pc
