18
Parts Required:
• Grease Drain Pan (Part #19) x1
Installation:
• Mount Grease Drain Pan (Part
#19) on the firebox. The tab should
be placed as shown.
Parts Required:
• Searing Station Pull Handle (Part
#22) x1
Installation:
• Insert Searing Station Pull Handle
(Part #22) through grommet on side
of firebox assembly.
• Align the flat end to the slot as
shown. Press it into when Daisy
Wheel is open.
• Turn the handle 90 degree as
shown to lock well.
Quick cooking food with pushing the
handle to open the Daisy Wheel .
Normal cooking when pulling the
handle out to close the Daisy Wheel.
