10
10
Attach Grill Body Assembly
9
12
11
Attach Handle, Heat Shield and Control Knobs
E
x 4
C
1
2
E
Insert Heat Plates and Cooking Grid
Insert Warming Rack
7
1
13
8
11
4
9
D
F
C
x 4
F
x 2
D
x 2
Note: Match up with the grill body holes and upper cart frame holes.
Install hardware and leave loose until 4 screws are attached then fully
tighten.
Note: Attach the warming rack end per 4 sequence.
1
2
3
4
Note: Fully tighten hardware.
To Next Page
