EXPERT GRILL GBC2016W - Parts Identification

7
1
Handle G2016-010
2
Lid* G1716-010
3
Brand Plate* B0109-LBD
4
Heat Plate (3) G1716-080
5
Top Hinge (2)* G1916-020
6
Bottom Hinge (2)* G1916-030
7
Heat Shield G1916-050
8
Warming Rack G1716-060
9
Cooking Grid G1716-070
10
Side Shelf (2) G2016-020
11
Grill Body Assembly G1916-040
12
Burner (3)* G1716-050
13
Control Knob (3) G1025-255
14
Grease Cup B0219-HA0
15
LP Gas Tank Heat Shield* G1916-060
16
Regulator/Hose Assembly* B0308-A18
17
LP Gas Tank Retainer Wire G1716-100
18
Front Panel G2016-030
19
Upper Cart Frame (2) G2016-050
20
Upper Left Support Wire G2016-070
21
Cart Rear Support G2016-040
22
Lighting Hook* B0223-D00
23
Lower Left Support Plate G2016-080
24
Longer Leg (2) G2016-060
25
Foot (2)* B0305-C00
26
Shorter Leg (2) G1816-340
27
Shorter Leg Connector G1716-190
28
Axle G2016-090
29
Wheel (2) B0302-EB0
* Pre-assembled
Hardware
A
Screw
M6x15 Nickel Plated Phillips Truss Head
4 pcs
B
Screw
M6x45 Nickel Plated Phillips Truss Head
10 pcs
C
Wing Screw
M6x16 Nickel Plated
4 pcs
D
Wing Nut
M6 Nickel Plated
4 pcs
E
Washer
ø6x16 Nickel Plated
4 pcs
F
Washer
ø6x22 Nickel Plated
2 pcs
G
Washer
ø11x20 Nickel Plated
1 pcs
H
Cotter Pin
ø1.4x30 Nickel Plated
1 pcs
Parts List
