380976-EU-EN-V3.2 6/12
13
KW+KVAR, KVA+
θ
(Phase Angle) or A+V displays.
6.
W
3
4W
= W
R(L1)
+ W
S(L2)
W
T(L3)
KVA K
KVARWW W34
2
34
2
34
PF
K
KVA
W
W
W
34
34
34
7. Set the rotary switch to another position to exit this mode and clear the stored data.
NOTE
1. The "+" sign printed on meter must face the power source for accurate
measurement.
2. If the device under test is switching power supply, the KW, PF and
θ
readings
may not be correct.
NOTE
For 3
4W power measurements, W
R
or W
S
and W
T
must be positive. If one shows
negative power, check the connections.
Resistance and Audible Continuity Measurements
WARNING
Before taking any in-circuit resistance measurements remove power from the circuit under test
and discharge all capacitors.
1. Set the rotary switch to the
‘Ω, ’
’
or ‘MΩ
’ position.
2. Insert the test leads into the input jacks. (Black to ‘COM’ and
Red to ‘
Ω’
)
3. Connect the test leads to the circuit or component under test.
4. Read the resistance value on the LCD.
5. For measurements < 40
Ω
, the continuity beeper will sound.
