Extech Instruments 382270 User Manual

Specifications
Range Specifications
Output1
(CH1)
Output2
(CH2)
Output3
(CH3)
Output4
(CH4)
0~30V/0~5A
0~30V/0~5A
3~6.5V/3A
8~15V/1A
Electrical Specifications
Input voltage: 110~127VAC±10%; 220~240VAC±10% (switchable)
Output voltage and current: See table above
Line regulation:
For Two adjustable outputs:
CV: ≤ 1 x 10ˉ
4
+ 3mV
CC ≤ 2 x 10ˉ
3
+ 3mA
Two semi-adjustable outputs: ≤ 5mV
Load regulation:
Two adjustable outputs:
CV ≤ 5 x 10ˉ
4
+ 5mV
CC ≤ 2 x 10ˉ
3
+ 5mA
CH3 ≤30mV
CH4 ≤15mV
Ripple and noise:
Two adjustable outputs:
CV ≤ 1mV rms
CC ≤ 3mA rms
Fixed output: ≤ 2mV rms
Protection: current-limit
Display accuracy:
Volt-indication: LED ± (0.5%rdg+2 digits)
Amp-indication: LED ± (0.5%rdg+2 digits)
General Specifications
Display: Four 3-digit color-coded LED displays and four status LED lights
Dimensions: 260 x 160 x 370mm (10.2 x 6.3 x 14.6") (W x H x D)
Weight: 12 kg (26.4lbs)
