Extech Instruments DL150 User Guide

DL150-EU-EN V2.5 5/13
6
Specifications
Display Multi-function LCD
Maximum data points 100,000
Channels Single channel, TRMS AC Voltage or Current
Sample rate 1s to 24h selectable
Transient capture >0.244mS
Analysis software Windows 2000/XP/ Vista/7/8
Data output USB port
Open input indication "LO" appears on the LCD
Low battery indication Empty battery symbol appears on the LCD
Power supply 4 AAA Batteries and 1 CR 3V memory button battery (CR2032 or
equivalent)
Battery life 5 days (approximately)
AC Adaptor 9V, 0.5A
Standards
C
C
CAT III 600V
Operating Temperature 0 to 50°C (32 to 122°F)
Operating Humidity <70% RH
Current Clamp Jaw opening 12.7mm (0.5”)
Dimensions 114 x 63 x 34mm (4.5 x 2.5 x 1.3”)
Weight 248g (8.7oz.)
Range Accuracy
Voltage
40Hz to 1kHz
10VAC to 600.0VAC ±2.0%±1V
Current
50/60Hz
10A to 200.0A ±2.0%±1A
Peak Measurement 8.0 to 850.0V ±5.0%
Copyright©2013FLIRSystems,Inc.
Allrightsreservedincludingtherightofreproductioninwholeorinpartinanyform
ISO‐9001Certified
www.extech.com
