EA11A-EU-EN v1.3 01/14
2
WARNING
To avoid electrical shock or personal injury, do not apply more than
20Vrms between the thermocouple inputs or between the thermocouple
and earth ground
Introduction
Congratulations on your purchase of the Extech EasyView™ Thermometer. This device offers a
single K-type thermocouple input with multifunction LCD display. This meter is shipped fully tested
and calibrated and, with proper use, will provide years of reliable service.
Safety
To prevent personal injury or meter damage, use the meter only as specified in this guide
Meter Description
Meter
1. Thermocouple input connector
2. LCD display
3. Function buttons
4. Battery compartment (rear)
Display
1. Low battery
2. Primary display
3. Memory location
4. Auto power off
5. Secondary display
6. Max, Min and Average
7. Temperature units
8. Read from memory location
9. Store to memory location
10. Hold
11. Offset
