IR200 V1.0 5/09
6
IR Measurement Notes
1. The object under test should be larger than the spot (target) size calculated by the field
of view diagram (printed on the side of the meter and in this guide).
2. Before measuring, be sure to clean surfaces that are covered with frost, oil, grime, etc.
3. If an object's surface is highly reflective, apply masking tape or flat black paint to the
surface before measuring. Allow time for the paint or tape to adjust to the temperature
of the surface it is covering.
4. Measurements through transparent surfaces such as glass may not be accurate.
5. Steam, dust, smoke, etc. can obscure measurements.
6. The meter automatically compensates for deviations in ambient temperature. However,
it can take up to 30 minutes for the meter to adjust to extremely wide changes.
Specifications
Range Accuracy
Body Temp 86.0 to 109
°
F (30 to 43
°
C) ±0.5°F/0.3°C
Surface Temp 32.0 to 140
°
F (0 to 60
°
C) ±1.5°F/0.8°C
Emissivity 0.95 fixed
Field of View D/S = Approx. 8:1 ratio (D = distance; S = spot or target)
IR Spectral response 6 to 14 μm (wavelength)
Display Backlit LCD display with function indicators
Response time 500ms
Over range indication “Hi“ or “Lo”
Operating Temperature 32
o
F to 122
o
F (0
o
C to 50
o
C)
Operating Humidity 10% to 90%RH operating, <80%RH storage.
Storage Temperature -4 to 140
o
F (-20 to 60
o
C)
Power Supply (2) AA” Batteries
Automatic Power Off 7 seconds (approx.),
Weight 6.24oz. (177g)
Dimensions 6.3 x 3.2 x 1.7” (160 x 82 x 42mm)
Calibration and Repair Services
Extech offers repair and calibration services for the products we sell. Extech also
provides NIST certification for most products. Call the Customer Service Department for
information on calibration services available for this product. Extech recommends that
annual calibrations be performed to verify meter performance and accuracy.
