Extech Instruments RH520A User Manual

5 RH520A-en-GB_v4.8 6/19
PUSH-BUTTON DESCRIPTION
VIEW Return the LCD to the Standard View
Escape from any setting function without storing value changes
Scrolls highest and lowest (MAX/MIN) readings when in Standard View
ALARM Display or Set alarm values
TIME Display a reading stored at specific Time and Date
Set and Display the recording Sampling Rate
Set the Time and Date
SET Used in combination with other buttons to set new parameter values
Stores new parameter values and returns to the Standard View
TEMP Used in combination with other buttons to set the vertical graph range
Used in combination with other buttons to set temperature alarm values
Used in combination with the RH button to display Dew Point
RH Used in combination with other buttons to set the vertical graph range
Used in combination with other buttons to set RH alarm values
Used in combination with the TEMP button to display Dew Point
Right, left, down, and up arrow buttons for scrolling data and navigating the
display

Extech Instruments RH520A Specifications

Temperature and Humidity

temperature range	-28 to 60 °C
temperature accuracy	±1.0 °C
humidity range	10 to 95 %
humidity accuracy	±3.0 % RH
dew point temperature	-28 to 60 °C

Power

power supply	Three ‘AA’ batteries and AC adaptor
dc voltage	5 V
battery life	4 weeks typical

Operating Environment

operating temperature range (control module and display)	0 to 50 °C
operating temperature range (sensor)	-28 to 60 °C
operating humidity (control module and display)	90 % RH max.

Memory and Data Logging

internal memory storage	49, 152 complete reading sets
sampling interval	0.1 to 199.9 minutes
alarm output current	3.4 mA @ 5 VDC

Weight and Dimensions

weight	357 g
dimensions	127 x 196 x 23 mm
