EU/UK Version 17 WTH600-E-en-GB_v1.0 4/18
The sensor transmits data wirelessly over an approximate range of 150m (line of sight).
Occasionally, due to intermittent physical obstructions or other environmental interference, the
signal may weaken or be lost. If the sensor signal is lost completely, please relocate the main unit
or the wireless sensor.
16. TEMPERATURE/HUMIDITY COMFORT LEVELS
Comfort Indication
The comfort pictorial indication is based on indoor air temperature and humidity.
Note:
1. Comfort indication can vary at the same temperature, depending on the humidity.
2. There is no comfort Indication when temperature is below 32°F (0°C) or above 140°F (60°C).
17. CLEARING STRAY READINGS
During installation of the wireless sensor, the sensors are typically triggered which results in
erroneous rainfall and wind measurements. After the installation, the user may clear all of the
erroneous data from the Main Unit, without having to reset the clock and re-establish pairing.
Simply press and hold the [HISTORY] button for 10 seconds. This will clear all data.
18. POINTING SENSOR TO THE SOUTH
The outdoor sensor is calibrated to be pointing to North by default. However, in some cases, users
may wish to install the product with the arrow pointing towards the South, especially for those
living in the Southern hemisphere (e.g. Australia, New Zealand).
1. Install the outdoor sensor with its arrow pointing to the South.
2. On the main unit, press and hold [WIND] for 8 seconds until the upper part (Northern
Hemisphere) of the compass lights and starts blinking.
3. Use [UP] / [DOWN] buttons to move to the lower part (Southern Hemisphere).
4. Press the [WIND] button to confirm and exit.
Note: Changing hemispheres will automatically switch the direction of the displayed moon phases.
