Extraflame BELLA - Page 10

10
TECHNICAL SPECIFICATIONS
All a.m. data are not binding, but valid just as an indication.
the right to make technical modifications for improving the product is reserved.
Height 1041 mm. 1068 mm.
Width 520 mm. 522 mm.
Depth 513 mm. 500 mm.
Weight 130 Kg. 150 Kg.
Fume exhaust pipe diameter 80 mm. 80 mm.
Max heating volume 150 m
3
180 m
3
Total power 2,5 - 7,5 kW/h 2,5 - 9,4 kW/h
Water power / kW/h / kW/h
Pellet consumption per hour 0,6 - 1,6 Kg/h 0,6 - 2,0 Kg/h
Absorbed electrical power 25 - 100 W 25 - 100 W
Lighting power +280 W +280 W
Power supply 230 V 50 Hz 230 V 50 Hz
Feed box capacity ~ 25 kg. ~ 25 kg.
Inlet/outlet water pipe “ / “ /
Bella Lux
Contessa
Bella Lux
Contessa
A: FUMES OUTLET PIPE Ø80
B: AIR INTAKE PIPE Ø 50
A: FUMES OUTLET PIPE Ø80
B: AIR INTAKE PIPE Ø 50
