WHAT IS THE PELLET?
14
SCRAPER
INTERNAL
DRAWER
gure 3.8
gure 3.9
gure 3.10
At this point, take the internal drawer and pull it
towards yourself to maximum opening: carry out this
operation with the aid of a common protection for
the hands or an oven glove in order to prevent burns
due to normal overheating of the metal parts during
functioning of the appliance.
Pour the pellet into the drawer and use the scraper to
push it into the ue tank, making sure that it does not
remain in the drawer.
After having lled the feed-box, repeat the operations in the reverse order to make the product go back to
its original state.
gure 3.11
During normal functioning the ue must always be as illustrated in the gure i.e. with the drawer completely
closed. The front pellet loading drawer must only be open for the loading time in order to prevent product
overheating.
