Extraflame LP30 Instructions For Assembly

INSTRUCTIONS FOR ASSEMBLY OF THE LP30 CYCLONE TANK LIDS
9
1
3
4
2
ENG
Instructions for assembly of the LP30 cyclone tank lids
Front door
Rear lid
Screw fasteners
Remove the rear lid by loosening
the 6 screw fasteners
Rear screw fastener Front lid
Font screw
fasteners
Remove the front lid, loosening
the front and rear screw fasteners
(it is recommended to remove
the front door to facilitate the
operations).
Assemble the front lid of the kit
using the previously-removed
screws
Assemble the rear lid using the
previously-removed screws (re-
mount the front panel)
