4.2 Cable range in assembly 1
4.3 Assembly 2 description
The Bluetooth handheld scanner can also be used separately in the hazardous area. The base or
charging station is then operated in the non-hazardous area.
Use an RS232 cable (iSCAN2XXCAB1 or 2) or a USB cable (iSCAN2XXCAB3 or 4) to connect the station
directly to a power supply and a PC.
The warnings and notes of caution contained in these operating instructions and in the
manual issued by SICK AG (www.SICK.com) must be adhered to.
1.8 or 3.8m
or optional with
4.5m or 6m
extension
