3.4 Technical data for base/charging station
Ambient temperature for
base station:
-20°C to +50°C
Bluetooth:
iSCAN211 and iSCAN211PDF:
Bluetooth V2.1 EDR, Class 2
2.4…2.4835 GHZ (ISM band)
iSCAN2012D:
Bluetooth V4.0 EDR, Class 1
2.4…2.4835 GHZ (ISM band)
Terminal assignment
(Handheld scanner)
USB cable
RS232 cable
USB/D+ green
USB/D- white
GND black
+UB brown
RS232-TXD white
GND brown
+UB yellow
Nominal values of
hazardous area base
station:
 maximum input voltage
Ui
4.9 V
 maximum input current
li
480 mA
 maximum input power
Pi
1.25 W
 maximum internal inductance
Li
negligible
 maximum internal capacitance
Ci
112.4 µF
If using a power supply other than iSCANPSx:
 maximum input voltage
Ui
5.6 V
 maximum input current
li
480 mA
 maximum input power
Pi
1.25 W
 maximum internal inductance
Li
negligible
 maximum internal capacitance
Ci
46 µF
Note: The input voltage in to the handheld scanner itself is reduced by the
associated connection cable ISCAN2XXCAB7 or 8 to 4.9V.
Nominal values of safe
area base station:
 operating voltage
U
5V
 power requirement
I
85 mA in standby mode
