Eyevision EV-IP-KP22 - Specifica Ons; Wiring Output

Working Voltage: DC 12-15V Standby Current: >=150mA <= 300 mA
Working Temperature: -20 °C ~ +50 °C Door Relay me 0-150 S (Adjustable)
Working Humidity <= 95%
Specificaons
Wiring Output
NO PIN Definion Funcon Remark
J1
1 NO 12V DC
(Brown)
E-lock power supply Magnec lock not
supported
2 NC(Orange) Normal close
3 COM(Green) Common
4 NO(Yellow) Normal open
5 EXIT(Black) Exit buon
6 DET(White) Door open status
protecon
7 GND(RED) Ground
1 White light LED
2 Camera
3 Photosensive
resistance
4 Keypad
5 Speaker
6 Call buon
7 Card area
8 Microphone
9 12V~15V DC in
10 RJ45 interface with
PoE
11 Lock control
